One minute to teach you about box rain test box

Rain test chamber product use: This product is suitable for testing the waterproof performance of automotive lamps, wipers, waterproof strips, locomotive instruments and low-voltage electrical appliances.

1. Technical parameters

1. Swing tube spray aperture: ø0.4

2. Spacing between spray holes: 50mm

3. Radius of water spray ring: R400mm / R500mm

4. Water pipe diameter: ø18mm

5. Swing angle of swing tube: ± 45 °, ± 60 °, ± 90 ° (specify when ordering)

6. Swing speed adjustment: stepless speed regulation

7. Water spray pressure: about 50 ～ 100kpa adjustable

8. Test time: adjustable from 1 to 9999 seconds, minutes and hours

9. Test bed speed: 1 ～ 5 ± 1r / min (adjustable speed, explain when ordering)

10. Number of water sprays: 23

2. Box structure

1. The inner tank of the rain test box is made of SUS304 stainless steel plate, and the outer shell material of the box body is made of high-quality steel plate. The spray pipe is also made of stainless steel; the nozzle is adjustable;

2. Stainless steel or copper materials are used in the studio and all other parts in contact with water.

Third, the control system

1. Speed ​​regulation device: The imported tube is adopted for the swing tube and turntable speed regulation.

2. Main configuration: water storage tank, water pump, decompression shunt device, pressure gauge, flow meter, water spray pipe assembly, swing tube swing drive mechanism, table rotation mechanism, electrical control system, visual tempered glass door, glass scraper Water heater, deceleration mechanism, etc.

Fourth, meet the standards

The company's products are manufactured in accordance with national standards GB10485-2007 automotive exterior lighting and signaling devices and automotive lamp shell protection and GB4208-2008 low-voltage electrical appliance shell protection standards

Note: This article is an original article of Beijing Yashilin Testing Equipment Co., Ltd. Please indicate the source when reprinting
